VN02H
| Manufacturer Part | VN02H |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IC PWR DRVR N-CH 1:1 5PENTAWATT |
| Category | Integrated Circuits (ICs) |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Obsolete |
| Switch Type: | General Purpose |
| Number of Outputs: | 1 |
| Ratio - Input:Output: | 1:1 |
| Output Configuration: | High Side |
| Output Type: | N-Channel |
| Interface: | On/Off |
| Voltage - Load: | 5V ~ 36V |
| Voltage - Supply (Vcc/Vdd): | Not Required |
| Current - Output (Max): | 6A |
| Rds On (Typ): | 400mOhm (Max) |
| Input Type: | Non-Inverting |
| Features: | Status Flag |
| Fault Protection: | Open Load Detect, Over Temperature |
| Operating Temperature: | -40°C ~ 150°C (TJ) |
| Mounting Type: | Through Hole |
| Supplier Device Package: | 5-PENTAWATT |
| Package / Case: | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
