30057
| Manufacturer Part | 30057 |
|---|---|
| Manufacturer | TTM Technologies, Inc. |
| Description | RF DIR COUPLER 4GHZ-8GHZ MODULE |
| Category | RF/IF and RFID |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Obsolete |
| Coupler Type: | Standard |
| Frequency: | 4GHz ~ 8GHz |
| Coupling Factor: | 3dB |
| Applications: | Military |
| Insertion Loss: | 0.8dB |
| Power - Max: | 80W |
| Isolation: | 15dB |
| Return Loss: | 10.2dB |
| Package / Case: | Module |
| Supplier Device Package: | - |
